Max DC 12V Relay Wireless RF Remote Control Switch Transmitter with Receiver

Description:

Adopt RF technology, with long remote control distance and stable signal.
Adjustable working way, control equipment turn/reverse, on/off. Switch Point lock,Self-locking,.
The programmable transmitter and receivers can be flexibly configured in quantity and in operating modes.
Adopt non-directional wireless encoding technology, allowing independent control without mutual interference.
Wide range of applications from simple domestic remote control to autonomous control,such as, window, entrance, Garage Doors, alarm system, lifting equipment and so on.

Specification:

Receiver Parameter
1.Working voltage: DC 12V
2.Quiescent Current: ≤ 8mA;Single Working Current ≤ 40 mA;Two Working Current (self-locking) ≤ 80 mA
3.Receive Sensitivity: ≥-105dBm
4.Working Frequency: 433MHz
5.Output Current: ≤ 10A
6.Weight: 0.05kg
7.Size:70x50x18mm/2.76x1.97x0.71inch
8.Working Mode: Point lock, Self-locking,
Transmitter Parameter
1.Working voltage: DC6V (CR2016)
2.Working current: ≤15mA
3.Quiescent current: 0mA
4.Working frequency: 433MHz
5.Chip type: 1527
6.Launch distance: 50m (empty environment)
7.Modulation method: ASK amplitude modulation
8.Size: 56.36x31.58x11.03mm/2.22x1.24x0.43inch

Package Includes:

1 Piece 12V two-way learning code controller
1 Piece waterproof two-button remote control

Note:

Do not operate with power. Turn off the power to operate, and use it after the test is confirmed to be correct.
When the voltage of the remote control is insufficient, please change the battery in time (the remote control distance becomes close when the voltage is insufficient).
Please pay attention to avoid metal or places with strong interference sources.
Do not use this electronic product abnormally.Abnormal use will reduce product performance and longevity. In severe cases, damage to the product will also pose a safety hazard.
