Max Maxb AC/DC12 -24V Input 18-24W LED Driver Power Supply IP67 Locomotive Lighting
Description:
IP67 Waterproof power supply driver to protect the electronic components against dust and submersion of water.
Use high quality aluminium material, does well in heat radiation, which guarantees the long-term stability of power supply.
Suitable for lamps DC 12-24V input 10 strings of 300mA floodlight, locomotive lighting, ship lighting, portable flood light.
Widely
used in commercial, industrial and household Indoor and Outdoor
Applications, also widely used in automation, communication and
industrial control equipment.
Specification:
Model: PL-DC-DC-320-64
Input Voltage: DC 12-24V
Input Power(load): 18-24W
Output Current(load): 300mA
Output Voltage: DC 30-80V (load); ≤ DC 85V(empty load)
Working Frequency: 50~60 Hz
Short Circuit Protection: Yes
Input-Housing AC 1.5KV/5mA 1Min
Waterproof: IP67
Ripple: ≤ 600 MVpp(120Hz)
Efficiency: ≥ 85 %
Working Temperature: -25℃~ +40℃
Material: Aluminium
Size: 90 x 30 x 20mm/ 3.54 x 1.18 x 0.79inch
Package Includes:
1 Piece 18-24W LED Driver Supply
Note:
Please allow 1-3mm error due to manual measurement.
Photo color might be a little different from the actual product due to color display of different monitors.
