Max AC 12V 3-9W RGB Built-in LED Drive Power Supply Module Gradient Drive
Description:
AC 12V input low voltage LED driver RGB power supply module board.
Number of LEDs: 1-3R 1-3G 1-3B, conventional RGB four-legged lamp bead, common anode, can also be customized common cathode, can also be used series or parallel with a single monochromatic lamp bead.
Commonly used in colorful underwater lights, buried lights, lawn lights, step lights, etc.
Built-in RGB.
Power: 3-9W.
Specification:
Input: Rated Voltage: AC 12V/24V
Output:
Output Current(Loading): 300mA x 3 ± 5 %
Output Voltage(loading): DC 2-5V
Output Voltage(no loading): ≤ DC 11.6 V
Short Circuit Protection: OK
Overloading: OK
Efficiency: ≥80%
Power Factor: ≥80%
Working Temperature: -25℃ ~ 40℃
Size: 58 x 27 x 11mm/2.28 x 1.06 x 0.43 inch
Package Includes:
1 Piece LED Driver Power Supply Board
