Maxbell Signal Relays Coil SPDT 8 Pins PCB General Purpose Power Relays 5 Pcs 12V
2
sold in last
8
hours
In stock
Rs. 2,150.00
Rs. 1,075.00
customers are viewing this product
Description:
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 5V 12V 24V DC (optional)
Contact current max.: 2A
Mounting: PCB
Specification:
AC contacts rating @R: 1 A / 125 VAC
DC contacts rating @R: 2 A / 30 VDC
Switched voltage: max 120V DC
Switched voltage: max 240V AC
Relay variant: subminiature
Coil resistance: 125Ω
Coil voltage min.: 3.75V DC
Coil voltage max.: 10V DC
Operate time: 7ms
Body dimensions: 20.2 x 10 x 11.5mm/0.79 x 0.39 x 0.45 inch
Release time: 4ms
Coil power consumption: 200mW
Operating temperature: -40~85℃
Contact resistance: 100mΩ
Terminal pitch: 5.08mm
Package Includes:
5 Pieces Signal Relay
