Maxbell Liquid Water Level Sensor Detector Monitoring Controller Module Multi Direction Precise Easy Cleanning Long Lifespan
Rs. 2,679.00Rs. 5,358.00
Description:
- Infrared Optical Principle: the level sensor converts the detected water level signal to electrical output for easy judgement.
- Compact design and waterproof, cylindrical shape to facilitate drilling installation.
- Multi installation forms, it can be set up in any direction.
- Superior in precision ,admissible error is within + 0.5mm .
- Easy to clean up,long lifespan
Specification:
- Working voltage : DC 5V [can be changed to 12V/24V for special requirements]
- Working current : <10MA
- Output way 1: Analog output 0-4.5V
...
✓ Secure checkout
✓ Quality checks before dispatch
✓ Customer support for order assistance
Product details
Description:
-
Infrared Optical Principle: the level sensor converts the detected water level signal to electrical output for easy judgement.
-
Compact design and waterproof, cylindrical shape to facilitate drilling installation.
-
Multi installation forms, it can be set up in any direction.
-
Superior in precision ,admissible error is within + 0.5mm .
-
Easy to clean up,long lifespan
Specification:
-
Working voltage : DC 5V [can be changed to 12V/24V for special requirements]
-
Working current : <10MA
-
Output way 1: Analog output 0-4.5V
-
Output way 2: High / low signal output
-
Response time : <500ms
-
Insulation resistance : 100MΩ
-
Working temperature : -30~80℃
-
Operating humidity :0-100% RH
-
Waterproof Features: Fully sealed waterproof design
-
Mounting : M15 * 12 hole
-
Lead Length: 19.68''/50cm
-
Size:Approx.1.18''X0.79''X0.47''/30mmX20mmX12mm
-
Material:Copper
Package Includes:
