Description:
Made of quality brass material, corrosion resistant and durable.
The fountain nozzle is for porous scattering.
The center of the water column and nozzle spraying formed two layers outward radiation parabolic spray.
Easy to install, it only requires PVC tubing and a submergible water pump.
Used in commercial and architectural fountains.
Specification:
Material: Brass
Color: Gold
1/4" Nozzle
Working Pressure: 40Kpa
Working Water Jet Capacity: 2M3/H
Jetting Height:Approx. 0.5M / 19.6"
Cover Diameter: Approx. 0.4M / 15.7"
1/2" Nozzle
Working Pressure: 40Kpa
Working Water Jet Capacity: 3Meter3/H
Jetting Height:Approx. 1M / 39.3"
Cover Diameter:Approx. 1.1M / 43.3"
3/4" Nozzle
Working Pressure: 40 Kpa
Working Water Jet Capacity: 5M3/H
Jetting Height: Approx. 1.2M / 47.2"
Cover Diameter:Approx. 1.3Meter / 51.1"
1" Nozzle
Working Pressure: 40Kpa
Working Water Jet Capacity: 7M3/H
Jetting Height: Approx. 1.5M / 59"
Cover Diameter:Approx. 1.5M / 59"
3/2" Nozzle
Working Pressure: 60Kpa
Working Water Jet Capacity: 10M3/H
Jetting Height: Approx. 1.8M / 70.8"
Cover Diameter: Approx. 1.6M / 63"
2" Nozzle
Working Pressure: 80Kpa
Working Water Jet Capacity: 12M3/H
Jetting Height: Approx. 2M / 78.7"
Cover Diameter: Approx. 2M / 78.7"
Size Chart:
1/4" Nozzle (Dia. x Height): Approx. 1.7cm x 3cm / 0.7" x 1.1"
1/2" Nozzle (Dia. x Height): Approx. 2.4cm x 4.5cm / 0.9" x 1.7"
3/4" Nozzle (Dia. x Height): Approx. 2.8cm x 5cm / 1.1" x 2"
1" Nozzle (Dia. x Height): Approx. 3.6cm x 8.5cm / 1.4" x 3.3"
3/2" Nozzle (Dia. x Height): Approx. 5cm x 8cm / 2" x 3.1"
2" Nozzle (Dia. x Height): Approx. 6.3cm x 9.5cm / 2.5" x 3.7"
Package Includes:
1 Piece Fountain Nozzle
Note:
The color may have different as the difference display, pls understand.
Please allow 1-4mm error due to hand test.
