Maxbell Maxbell 2 Pin Power Connector Male Plug & Female Socket Waterproof Outdoor IP67

Description:

2 cores, in line with the diversity of industrial demand, signal and power compatible match
PBT material of the protective housing, with characters of fire safety, compression, anti-explosion and anti-deformation
Gold-plated contacts, high-strength corrosion resistance and electrical conductivity, effective response to temperature changes in current
1/4 Quick bayonet coupling, simple operation, easy installation
Dustproof cover design under off-working condition
20A rms current rating
Protection level:IP67

Specification:

Cable specification 2.5m㎡～4m㎡/14-12 AWG
Diameter range Φ8mm～Φ12mm
Contact diameter × number Φ2.7x2
Rated Current (A) 20A
Operating voltage (AC.V.rms) 500V
Contact resistance <1mΩ
Temperature rise 20A contact temperature below 30℃,25A ......40℃↓,30A......50℃↓
Withstanding Voltage (AC.V) 1 minute 2500V
Insulation resistance ＞500MΩ
Protection level IP67
Durability ≥500 times
Working temperature -40℃～80℃
Connecting mode 1/4 bayonet connect
Assembly wire Solder
Housing, the insulating parts High-performance engineering plastics
Hardware Zinc Alloy (pearl hard chrome)
Copper needles Copper alloy (gold-plated 4U)
Waterproof circle Silica gel
Flammability rating UL94-V0

Package Includes:

1 piece 2 Pin Power Connector
