Maxbell 1 Pc Original External S Meter SWR Watt Power Meter for Yaesu FT-857 FT-897

Description:

Receive Display Settings:
1, press [FUNC] key to enter the setup menu, enable the extended menu.
2, rotate [SELECT] to call up the setup menu item No-060 [MTR ARX SEL].
3, rotate [DIAL] to select an external instrument display:
SIG: the input signal strength display
C T R: Discriminator Center Meter
VLT: battery voltage
N / A: blank
FS: buckle in the instrument 1mA full scale output signal calibration standard external instruments
OFF:Turn off the meter.
4, press [FUNC] button to save the settings and exit the setup menu.

Emission Display Settings:
1, press [FUNC] key to enter the setup menu, enable the extended menu.
2, rotate [SELECT] to call up the setup menu item No-061 [MTR ATX SEL].
3, rotate [DIAL] to select an external instrument display:
PWR: transmit power display
ALC: Automatic Level Control voltage display
MOD: Modulation Level Display
SWR: SWR display
VLT: Display Supply Voltage
N / A: blank
OFF: Turn off the meter.

Specification:

Material: Plastic

Size: Approx.12x15x12 cm / 4.72x5.91x4.72 inch

Package Includes:

1 Pc Power Meter

Note:

1.If you can not find the numbers 60, 61 menu, is this two radio hidden menu. Long press the F key to open the menu settings, the 1st menu set to ON, press the F key to open the exit to save the hidden menu.

2.Please allow 1-3cm error between the size from the above and the actual item due to manual measurement.
